Specifications

General type
Colour printer for A4 format

Engine speed
Up to 35 pages per minute in A4 in colour and b/w; duplex print speed: 17.5 page per minute A4

Warm-up time
Approx. 23 seconds or less from power on

Power consumption
Printing: 466 W, Ready mode: 56 W, Sleep-mode: 0.6 W



PAPER HANDLING

Input capacity
100-sheet multi-purpose tray, 60–220 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (70 x 148 to 216 x 356 mm), 500-sheet Standard universal paper cassette, 60–163 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm).Max. input capacity with options: 2,100 sheets A4

Max. input capacity with options
2,300 sheets with 75 g/m2

Duplex unit
Standard duplex unit: 60–163 g/m² (A4, A5, B5, Letter, Legal)

Output capacity
250-sheet face-down with paper full sensor



PRINT

Processor
ARM Cortex-A9 D.core 1,2GHz + ARMCortex-M3 100MHz

Fonts
93 outline fonts (PCL), 93 fonts (KPDL 3), 8 fonts (Windows Vista), 1 Bitmap font, 45 types of onedimensional barcodes, 1 type of two-dimensional barcode (PDF417)

Features
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality



PAPER HANDLING OPTIONS

PF-5150 Paper feeder

Capacity in sheets 550 sheets with 75 g/m2

Dimensions (W x D x H) 380 x 410 x 121 mm

Paper Size 60 - 120g/m2, A4, A5, B5, Letter, Legal Custom (92 - 216 x 162 - 356 mm)



CONSUMABLES

TK-5374K
Average continuous black toner yield 7,000 pages in accordance with ISO /IEC 19798. Capacity of starter toner: Average continuous black toner yield 3,500 pages in accordance with ISO /IEC 19798

TK-5374C
Average continuous cyan toner yield 5,000 pages in accordance with ISO /IEC 19798. Capacity of starter toner: Average continuous cyan toner yield 2,500 pages in accordance with ISO /IEC 19798

TK-5374M
Average continuous magenta toner yield 5,000 pages in accordance with ISO /IEC 19798. Capacity of starter toner: Average continuous magenta toner yield 2,500 pages in accordance with ISO /IEC 19798

TK-5374Y
Average continuous yellow toner yield 5,000 pages in accordance with ISO /IEC 19798. Capacity of starter toner: Average continuous yellow toner yield 2,500 pages in accordance with ISO /IEC 19798



OPTIONS

HD-17
64GB SSD storage for easy document management

HD-18
256GB SSD storage for easy document management

HD-19
512GB SSD storage for easy document management

IB-37
Wireless Network Interface (USB: 5GHz/2.4GHz)

IB-50
Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT

IB-51
Wireless LAN Interface (802.11b/g/n) (Note: Requires Labour Call Out Fee for Installation)

UG-33 AC
ThinPrint support (Licence)

UG-35
TPM (Trusted Platform Module)

USB IC Card Reader + Card Authentication Kit (B) AC
Support for various authentication keys available

1244/10 Cabinet
For 2 draw configuration

AC41366
SD CARD 32GB SDHC CLASS 10 MEMORY CARD - 120MB
