• Description

    Description

    With exceptional performance and secure design, the XC2335 Multifunction printer (copy/scan/print/fax) delivers enhanced productivity of up to 33 pages per minute* and toner yields of up to 20,000 pages mono, and up to 11,700 pages colour**. Engineered for long life with environmental certifications and advanced power management, this efficient model has high sustainability. Fast time to first print, superior print quality and easy-to-use touch screen. Our sophisticated, IoT-ready printers are loaded with sensors that continuously monitor hundreds of data points that provide added benefits, like predictive service and automatic supplies replenishment, when they are connected to Lexmark Cloud Services. With the large, buttonless touch screen, the user can intuitively perform tasks. Workflow solutions, like Scan Centre for simple document routing, are standard.


  • SPECIFICATIONS

    Specifications

    With exceptional performance and secure design, the Lexmark XC2335 Multifunction printer (copy/scan/print/fax) delivers enhanced productivity of up to 33 pages per minute* and toner yields of up to 20,000 pages mono, and up to 11,700 pages colour**. Fast time to first print, superior print quality and easy-to-use touch screen.

    Part Number
    50M7197
    Print Technology
    Colour Laser Printer
    Function
    Colour Copying
    Colour Printing
    Colour Scanning
    Trusted Platform Module (TPM)
    The Trusted Platform Module (TPM) is not available in some countries.
    Analogue Fax
    Workgroup Size
    Medium Workgroup
    Touch Screen Display
    Yes
    Display
    Lexmark e-Task 10.9 cm colour touch screen with audible feedback
    Print Speed (A4, Black)
    Up to 33 ppm4
    Print Speed (A4, Colour)
    Up to 33 ppm4
    Print Speed (A4, Black) Duplex
    Up to 17 spm4
    Print Speed (A4, Colour) Duplex
    Up to 17 spm4
    Time to First Page (Black)
    As fast as 7.2 seconds
    Time to First Page (Colour)
    As fast as 7.5 seconds
    Duplex (2-sided) Printing
    Integrated Duplex
    Print Resolution, Black
    1200 x 1200 dpi
    4800 Colour Quality
    Print Resolution, Colour
    1200 x 1200 dpi
    4800 Colour Quality
    Copy Speed (A4, Black)
    Up to 33 cpm4
    Copy Speed (A4, Colour)
    Up to 33 cpm4
    Copy Speed (A4, Black) Duplex
    Up to 17 spm4
    Copy Speed (A4, Colour) Duplex
    Up to 17 spm4
    Time to First Copy (Black)
    As fast as 7.7 seconds
    Time to First Copy (Colour)
    As fast as 7.7 seconds
    Reduce / Enlarge Range
    25 - 400 %
    A4/Ltr Simplex Scan Speed (Black)
    Up to 49 / 52 sides per minute
    Scan Speed (A4/Ltr, Colour)
    Up to 34 / 36 sides per minute
    A4/Ltr Duplex Scan Speed (Black)
    Up to 98 / 104 sides per minute
    Duplex Scan Speed (A4/Ltr, Colour)
    Up to 68 / 72 sides per minute
    ADF Scan
    DADF (single pass Duplex)
    Scan Technology
    CIS
    Scan Resolution, Enhanced
    Up to 600 X 600 dpi
    Scan Resolution, Optical
    Up to 600 dpi
    Scan File Formats (Send as)
    JPEG, JPG
    PDF
    Secure PDF
    TIFF
    XPS
    BMP
    Archival PDF (A-1a, A-1b)
    Searchable PDF (50M7190, 50M7191, 50M7192, 50M7193, 50M7196)
    Scan Destinations
    e-mail
    FTP
    USB Flash drive
    USB or Network connected computer
    Lexmark Document Solutions Suite (LDSS)
    Modem Speed
    ITU T.30, V.34 Half-Duplex, 33.6 Kbps
    Fax Transmission Speed
    < 3 seconds per page
    Processor Speed
    Quad Core, 1.2 GHz
    Memory, Standard
    2048 MB
    Memory, Maximum
    2048 MB
    Apple Operating Systems Supported
    Support is provided through AirPrint and AirScan only
    Citrix MetaFrame
    Microsoft Windows Server 2012 R2 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16
    Microsoft Windows Server 2012 Datacenter Edition running Citrix XenApp 7.5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16
    Microsoft Windows Server 2012 Foundation running Citrix XenApp 6.0, 6.5
    Microsoft Windows Server 2012 Essentials running Citrix XenApp 6.0, 6.5
    Microsoft Windows Server 2012 Standard running Citrix XenApp 6.0, 6.5
    Linux Operating Systems Supported
    Ubuntu 20.04
    Debian 10
    SUSE Linux Enterprise Server 12 SP5
    OpenSUSE 15.2
    Debian 11
    Ubuntu 22.04
    Fedora 36
    Fedora 37
    SUSE Linux Enterprise Server 15 SP4
    OpenSUSE 15.4
    Red Hat Linux 8.7
    Red Hat Linux 9.1
    Microsoft Windows Operating Systems Supported
    Windows 7
    Windows 7 x64
    Windows 8
    Windows 8 x64
    Windows Server 2012
    Windows 8.1
    Windows Server 2012 R2
    Windows 10
    Windows Server 2016
    Windows Server 2019
    Windows Server 2022
    Windows 11
    Novell Operating Systems Supported
    Novell NetWare 6.5 Open Enterprise Server
    Novell Open Enterprise Server 2 (SP3) on SuSE Linux Enterprise Server 10 SP4 (x86 and x64) 3
    Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64)
    Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 12 SP1 (x86 and x64)
    Novell Open Enterprise Server 15 (SP1) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64)
    Other Operating Systems Supported
    Virtually any platform supporting TCP/IP
    Included Paper Handling
    Integrated Duplex
    200-Sheet Output Bin
    Single sheet multipurpose feeder
    250-Sheet Tray
    Optional Paper Handling
    550-Sheet Tray
    650-Sheet Duo Tray
    Paper Input Capacity, Standard
    Up to 251 pages 75 gsm bond
    Paper Input Capacity, Maximum
    Up to 2001 pages 75 gsm bond
    Paper Output Capacity, Standard
    Up to 200 pages 75 gsm bond
    Paper Output Capacity, Maximum
    Up to 200 pages 75 gsm bond
    Paper Weight Range Supported - Standard Tray (gsm)
    60 - 218 gsm
    Paper Weight Range Supported - Multipurpose Feeder (gsm)
    60 - 176 gsm
    ADF
    100-Sheet Automatic Document Feeder
    ADF Paper Input Capacity
    Up to 100 pages 75 gsm bond
    ADF Paper Output Capacity
    Up to 100 pages 75 gsm bond
    Number of Paper Inputs, Standard
    2
    Number of Paper Inputs, Maximum
    6
    Media Types Supported
    Card Stock
    Envelopes
    Paper Labels
    Plain Paper
    Vinyl Labels
    Refer to the Paper & Specialty Media Guide
    Media Sizes Supported
    10 Envelope
    7 3/4 Envelope
    9 Envelope
    A4
    A5
    B5 Envelope
    C5 Envelope
    DL Envelope
    Hagaki Card
    Executive
    Folio
    JIS-B5
    Legal
    Letter
    Statement
    Universal
    Oficio
    A6
    Standard Ports
    USB 2.0 Specification Hi-Speed Certified (Type B)
    Gigabit Ethernet (10/100/1000)
    Front USB 2.0 Specification Hi-Speed Certified port (Type A)
    Rear USB 2.0 Specification Hi-Speed Certified port (Type A)
    802.11a/b/g/n/ac + Apple iBeacon
    Network Protocol Support
    TCP
    UDP
    IPSEC w/ IPv4
    IPSEC w/ IPv6
    ICMP
    IGMP
    IPv4
    IPv6
    Network Security
    Certificate Management
    SSL Cipher Configuration
    TCP/UDP Port Access Control
    Security Port Lockdown
    TCP Restricted Server List
    IPSEC Support (IPv4/IPv6)
    Printable Area (metric)
    4.2 mm of the top, bottom, right and left edges (within)
    Printer Languages (Standard)
    PCL 6 Emulation
    Personal Printer Data Stream (PPDS)
    PostScript 3 Emulation
    Direct Image
    PDF 1.7 emulation
    PCL 5
    Fonts and Symbol Sets
    39 scalable PPDS fonts
    5 PPDS bitmap fonts
    2 PCL 6 bitmap fonts
    94 scalable PCL 6 fonts
    163 scalable PostScript fonts
    OCR-A, OCR-B (50M7190, 50M7191, 50M7192, 50M7193, 50M7196)
    Laser Cartridge Yields (up to)3

    20,000-page Black Cartridge
    11,700-page Colour (CMY) Cartridges
    Imaging Kit Yield
    Up to 150,000 pages, based on 3 average letter/A4-size pages per print job and ~ 5% coverage
    Cartridge(s) Shipping with Product
    2,000-page Colour (CMY) Return Program Toner Cartridges
    3,000-page Black Return Program Toner Cartridge
    Replacement Cartridges:
    Product functions only with replacement cartridges designed for use in a specific geographical region. See www.lexmark.com/regions for more details.
    Packaged Size (mm - H x W x D)
    600 x 636 x 575 mm
    Packaged Weight, kg
    32.3 kg
    Size (mm - H x W x D)
    491.4 x 479 x 475.1 mm
    Weight
    27.05 kg
    Noise Level, Idle
    14 dBA
    Noise Level (Print), Operating
    50 dBA
    Duplex Print Noise Level, Operating
    52 dBA
    Noise Level (Copy), Operating
    50 dBA
    Noise Level (Scan), Operating
    43 dBA
    Quiet Mode
    47 dBA
    ENERGY STAR
    Yes
    Average Power (Hibernate Mode)
    0.2 watts
    Average Power (Sleep Mode)
    1.3 watts
    Average Power (Ready Mode)
    25.5 watts
    Average Power (Printing)
    574 watts
    Average Power while Printing Duplex
    383 watts
    ENERGY STAR Typical Electricity Consumption (TEC)
    0.51 kilowatt-hours per week
    Product Warranty
    1-year Onsite Service + 3-years Parts Only guarantee (Maintenance Kit included)
    Product Certifications
    ENERGY STAR, Blue Angel RAL-UZ 219, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62368-1, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55035, UL), EFTA (CE), KCC, CCC, CECP, CEL, UL-AR, KC mark, UL GS mark, UCRF, EC 1275, Mopria Certified
    Maximum Monthly Duty Cycle
    Up to 100,000 pages per month2
    Recommended Monthly Page Volume
    1500 - 10000 pages1
    Specified Operating Environment
    Humidity: 15 to 80% Relative Humidity
    Temperature: 10 to 32.2°C (50 to 90°F)
    Altitude: 0 - 2900 metres
    License/Agreement Terms
    Printers are sold subject to certain license/agreement conditions. See www.lexmark.com/printerlicense for details.
    Country of Origin
    China (PRC)
    Mexico
    UNSPSC Code
    43212110

    1"Recommended Monthly Page Volume" is a range of pages that helps customers evaluate Lexmark’s product offerings based on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per month be within the stated range for optimum device performance, based on factors including: supplies replacement intervals, paper loading intervals, speed, and typical customer usage.

    2"Maximum Monthly Duty Cycle" is defined as the maximum number of pages a device could deliver in a month using a multishift operation. This metric provides a comparison of robustness in relation to other Lexmark printers and MFPs.

    3Average yield based on approximately 5% print coverage.

    4Print and copy speeds measured in accordance with ISO/IEC 24734 and ISO/IEC 24735 respectively (ESAT). For more information see: www.lexmark.com/ISOspeeds.
